GB/T 22589-2017 镁碳砖/magnesia carbon brick
镁碳砖
1.范围
本标准规定了镁碳砖的分类和牌号、技术要求、试验方法、质量评定程序、包装、标志、运输、储存及质量证明书。
本标准适用于炼钢转炉、电炉、钢包(精炼炉)等用的镁碳砖。
2.规范性引用文件。
下列文件对于本文件的应用是必不可少的，凡是注日期的引用文件,仅注日期的版本适用于本文件。凡是不注日期的引用文件，其最新版本(包括所有的修改单)适用于本文件。
GB/T 2997致密定形耐火制品体积密度、显气孔率和真气孔率试验方法。
GB/T 3002耐火材料，高温抗折强度试验方法。
GB/T 5072耐火材料 常温耐压强度试验方法。
GB/T 7321定形耐火制品试样制备方法。
GB/T 10325定形耐火制品验收抽样检验规则。
GB/T 10326定形耐火制品尺寸、外观及断面的检查方法。
GB/T 16546定形耐火制品包装、标志、运输和储存。
GB/T 16555今碳、碳化硅、氮化物耐火材料化学分析方法。
GB/T 21114耐火材料 X射线费光光谱化学分析熔铸玻璃片法。
3.分类和牌号
3.1镁碳砖按碳含量分为7类,按理化指标分为 26 个牌号,见表1牌号中M、T为镁、碳汉语拼音首字母，其后的数字表示碳的质量分数，A、B、C、D 则是同类的不同级别。
|
表1镁碳砖的分类和牌号 |
||||||
|
MT-5A |
MT-8A |
MT-10A |
MT-12A |
MT-14A |
MT-16A |
MT-18A |
|
MT-5B |
MT-8B |
MT-10B |
MT-12B |
MT-14B |
MT-16B |
MT-18B |
|
MT-5C |
MT-8C |
MT-10C |
MT-12C |
MT-14C |
MT-16C |
MT-18C |
|
MT-5D |
MT-8D |
MT-10D |
MT-12D |
MT-14D |
|
|
3.2 对于有特殊要求的产品，由供需双方协商确定。
4.技术要求
4.1镁碳砖的理化指标应符合表 2 的规定。
|
表2镁碳砖的理化指标 |
||||||||||||
|
牌号 |
显气孔率/% |
体积密度/(g/cm-3) |
常温耐压强度/MPa |
高温抗折强度 (1400 CX0. 5 h)/MP
|
w(MgO)/% |
w(C)/% |
||||||
|
μ0≤ |
σ |
μ0≥ |
σ |
μ0 |
σ |
μ0≥ |
σ |
μ0≥ |
σ |
μ0≥ |
σ |
|
|
MT-5A |
5.0 |
1.0 |
3.10 |
0.05 |
50.0 |
10.0 |
– |
– |
85.0 |
1.5 |
5.0 |
1.0 |
|
MT-5B |
6.0 |
3.02 |
50.0 |
– |
– |
84.0 |
5.0 |
|||||
|
MT-5C |
7.0 |
2.92 |
45.0 |
– |
– |
82.0 |
5.0 |
|||||
|
MT-5D |
8.0 |
2.90 |
40.0 |
– |
– |
80.0 |
5.0 |
|||||
|
MT-8A |
4.5 |
3.05 |
45.0 |
– |
– |
82.0 |
8.0 |
|||||
|
MT-8B |
5.0 |
3.00 |
45.0 |
– |
– |
81.0 |
8.0 |
|||||
|
MT-8C |
6.0 |
2.90 |
40.0 |
– |
– |
79.0 |
8.0 |
|||||
|
MT-8D |
7.0 |
2.87 |
35.0 |
– |
– |
77.0 |
8.0 |
|||||
|
MT-10A |
4.0 |
0.5 |
3.02 |
0.03 |
40.0 |
6.0 |
1.0 |
80.0 |
10.0 |
|||
|
MT-10B |
4.5 |
2.97 |
40.0 |
– |
– |
79.0 |
10.0 |
|||||
|
MT-10C |
5.0 |
2.92 |
35.0 |
– |
– |
77.0 |
10.0 |
|||||
|
MT-10D |
6.0 |
2.87 |
35.0 |
– |
– |
75.0 |
10.0 |
|||||
|
MT-12A |
4.0 |
2.97 |
40.0 |
6.0 |
1.0 |
78.0 |
1.2 |
12.0 |
||||
|
MT-12B |
4.0 |
2.94 |
35.0 |
– |
– |
77.0 |
12.0 |
|||||
|
MT-12C |
4.5 |
2.92 |
35.0 |
– |
– |
75.0 |
12.0 |
|||||
|
MT-12D |
5.5 |
2.85 |
30.0 |
– |
– |
73.0 |
12.0 |
|||||
|
MT-14A |
3.5 |
2.95 |
38.0 |
10.0 |
1.0 |
76.0 |
14.0 |
|||||
|
MT-14B |
3.5 |
2.90 |
35.0 |
– |
– |
74.0 |
14.0 |
|||||
|
MT-14C |
4.0 |
2.87 |
35.0 |
– |
– |
72.0 |
14.0 |
|||||
|
MT-14D |
5.0 |
2.81 |
30.0 |
– |
– |
68.0 |
14.0 |
|||||
|
MT-16A |
3.5 |
2.92 |
35.0 |
8.0 |
8.0 |
1.0 |
74.0 |
16.0 |
0.8 |
|||
|
MT-16B |
3.5 |
2.87 |
35.0 |
– |
– |
72.0 |
16.0 |
|||||
|
MT-16C |
4.0 |
2.82 |
30.0 |
– |
– |
70.0 |
16.0 |
|||||
|
MT-18A |
3.0 |
2.89 |
35.0 |
10.0 |
1.0 |
72.0 |
18.0 |
|||||
|
MT-18B |
3.5 |
2.84 |
30.0 |
– |
– |
70.0 |
18.0 |
|||||
|
MT-18C |
4.0 |
2.79 |
30.0 |
– |
– |
69.0 |
18.0 |
|||||
|
注:μ0代表合格质量批均值，σ代表批标准偏差估计值. |
||||||||||||
4.2 砖的形状尺寸可由供需双方协商确定,砖的尺寸偏差及外观要求应符合表3 的规定。
|
表3镁碳砖的尺寸允许偏差及外观 单位为毫米 |
|||
|
项 目 |
指 标 |
||
|
尺寸允许偏差 |
尺寸 |
<200 |
士1.0° |
|
201~300 |
士1.5 |
||
|
>300 |
士2.0 |
||
|
扭曲 |
长度 |
≤500 |
≤1.0 |
|
>500 |
≤1.5 |
||
|
缺角(a+b+c) |
≤25 |
||
|
缺棱(e+f+g) |
30 |
||
|
裂纹宽度 |
≤0.1 |
不限制 |
|
|
>0.1 |
不准有 |
||
|
楔度差 |
≤1.5 |
||
|
砌筑环高方向尺寸偏差 |
士1.0 |
||
|
相对边差 |
≤1.0 |
||
|
断面层裂 |
不准有 |
||
|
平砌时，宽度尺寸允许偏差±1.5mm；侧砌时，厚度尺寸允许偏差±1.5mm。 |
|||
5 试验方法
5.1 砖的检验制样按 GB/T 7321 进行。
5.2化学分析按 GB/T 16555、GB/T 21114 进行。
5.3显气孔率、体积密度的测定按 GB/T 2997 进行。
5.4常温耐压强度的测定按 GB/T 5072 进行。
5.5高温抗折强度的测定按 GB/T 3002 进行。
5.6 砖的尺寸、外观及断面的检查按 GB/T 10326 进行。
6质量评定程序
6.1组批
产品按同一牌号组批，每批不应超过150t。
6.2 抽样及合格判定规则
产品的抽样、验收按 GB/T 10325 进行,显气孔率、体积密度、常温耐压强度及 MgO,C 的含量为验收检验项目。
6.3 合格评定形式
合格评定可采用供货方声明、使用方认定或第三方认证的形式进行。
7.包装、标志、运输、储存及质量证明书
7.1产品的包装、标志、运输和储存按 GB/T 16546 进行。
7.2运输和储存中，产品应严防潮湿。
7.3 砖发出时应附有供方质量部门签发的质量证明书，质量证明书应载明供方名称或厂标、需方名利发货日期、合同号、标准编号、产品名称、牌号、砖号、批号及相应的理化检验结果等。
